1U Angled Rear Cable Manager
Nimikenumero 854-05154 | APARCM1U Yksityiskohdat

Tämä tuote ei ole enää saatavana!
  • Provides cable strain relief
  • Available in 1U or 2U versions
  • Maximum of 48 cables using 1U version
Colour Black (BK)
Package Content packed in box
PART DESCRIPTION APARCM1U
Product Description The HellermannTyton Angled Cable Managers fit easily on to the HellermannTyton range of angled panels. The Angled Rear Cable Manager comes in 1U and 2U versions and is manufactured from 1.6mm matt black powder coated mild steel. The 1U version is suitable for use with any HellermannTyton angled 1U 24 port, 1U port or 2U 48 port panel providing strain relief for up to 48 cables. The 2U version can be used with any HellermannTyton 2U angled panel providing strain relief for a maximum of 72 cables.
Product Family Cabinet Cable Management
Product Group 1U Angled Rear Cable Manager
Short Description 1U Angled Rear Cable Manager
Height (H) 44mm
Width (W) 483mm
Country of Origin GB
Dimensions W x H x D 483 mm x 44 mm x
GTIN-13 / EAN 5022660123108
ETIM 7.0 Key EC002624
ETIM 8.0 Key EC002624
ETIM 9.0 Key EC002624
